Engine Type: 4 Cylinders
Displacement: 3.9 L
Bore x Strock: 102 mm * 120 mm
Rated Power: 50 HP to 130 HP
Emission Standard: N/A
Non-Listed Pump Engine
Cummins pump products include low power engines covering displacement of 3.9 to 13 L. with power range from 36 kW to 429 kW. Heavy-duty and high-power diesel engines with a displacement of 11-50 liters and their components, with a power range of 175-2200 HP. The products are widely used in fixed and mobile water pump stations, fire pumps, mud pumps, sand dredgers, etc. Its excellent dynamic performance, economy, reliability, durability and safety are unanimously praised by users around the world.
SinoMac is a partner of PumpMac for many years, we are a professional pump system solution supplier with many years of experience. We provide customers from all over the world with one-stop pump system solutions from pump system design to pump system supply, from installation to commissioning, and from after-sales. Providing sales service support for spare parts supply, SinoMac is your reliable pump system partner, providing you with the best value for money and reliable system solutions.
Advantages of Non-Listed Pump Engine
Powerful and efficient- Compared with engines of the same type, both the torque reserve coefficient and the power are higher, which meet complicated operating conditions.
Better environmental adaptability-After extensive tests in harsh environments such as plateaus, high temperature, high humidity and low temperature, it adapts to extreme operating conditions
Lower noise through optimization of the control strategy and application of noise reduction options
The “heart” of CMS engines preserves higher value of your equipment.
The 2900-rpm engine is directly connected to the pump, meeting the performance requirements of high-speed pumps and reducing the matching cost.
| 36 – 97 kW | ||||||||
| 92 – 153 kW | ||||||||
| 151 – 194 kW | ||||||||
| 179 – 264 kW | ||||||||
| 412 – 478 kW | ||||||||
| 36 – 85 kW | ||||||||
| 96 – 120 kW | ||||||||
| 118 – 170 kW | ||||||||
| 206 – 235 kW | ||||||||
| 340 – 429 kW | ||||||||
| 338 – 412 kW | ||||||||
|
Engine Model Power/kW |
0 | 100 | 200 | 300 | 400 | 500 | 600 | 700 |
| Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ | ||||||||
| Non-Approval Pump Engine Catalogue |
| 224 – 373 kW | ||||||||
| 522 – 1112 kW | ||||||||
| 1227 – 1657 kW | ||||||||
| 1044 – 1864 kW | ||||||||
|
Engine Model Power/kW |
0 | 250 | 500 | 750 | 1000 | 1250 | 1500 | 1750 |
| Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ | ||||||||
| CCEC Pump Engine Catalogue |
Find Non-Listed Pump Engines by Series
This is the list of all series of non-listed pump engines.
Click here to find non-listed pump engines by type (Fuel System & Engine Speed).
6BT5.9 | 92-153 kW
Engine Type: 6 Cylinders
Displacement: 5.9 L
Bore x Strock: 102 mm*120 mm
Rated Power: 125 HP to 205 HP
Emission Standard: Euro Stage II
6CTA8.3 | 151-194 kW
Engine Type: 6 Cylinders
Displacement: 8.3 L
Bore x Strock: 114 mm*135 mm
Rated Power: 205 HP to 260 HP
Emission Standard: Euro Stage II
6LTAA8.9 | 179-264 kW
Engine Type: 6 Cylinders
Displacement: 8.9 L
Bore x Strock: 114 mm*145 mm
Rated Power: 179 – 264 kW @ 1500 – 3000 RPM
Emission Standard: Euro Stage II
QSB3.9 | 36-85 kW
Engine Type: 4 Cylinders
Displacement: 3.9 L
Bore x Strock: 102 mm * 120 mm
Rated Power: 50 HP to 115 HP
Emission Standard: N/A
QSB5.9 | 96-120 kW
Engine Type: 6 Cylinders
Displacement: 5.9 L
Bore x Strock: 102 mm * 120 mm
Rated Power: 130 HP to 160HP
Emission Standard: N/A
QSB6.7 | 118-170 kW
Engine Type: 6 Cylinders
Displacement: 6.7 L
Bore x Strock: 107 mm * 124 mm
Rated Power: 158 HP to 227 HP
Emission Standard: N/A
QSZ13 | 286-429 kW
Engine Type: 6 Cylinders
Displacement: 13 L
Bore x Strock: 130 mm * 163 mm
Rated Power: 383 HP to 575 HP
Emission Standard: EU Stage IIIA
QSZ14 | 338-412 kW
Engine Type: 6 Cylinders
Displacement: 13.48 L
Bore x Strock: 107 mm * 124 mm
Rated Power: 453 HP to 552 HP
Emission Standard: CH SG3
QSL8.9 | 206-235 kW
Engine Type: 6 Cylinders
Displacement: 8.9 L
Bore x Strock: 114 mm*145 mm
Rated Power: 206 – 235 kW @ 1500 RPM
Emission Standard: Euro Stage II
KTA38 | 522-1112 kW
Engine Type: 12 Cylinder
Displacement: 38 L
Bore x Strock: 159 mm * 159 mm
Rated Power: 522 – 1112 kW @ 1500 – 1800 RPM
Emission Standard: N/A
NTA855 | 224 – 373 KW
Engine Type: 6 Cylinder
Displacement: 14 L
Bore x Strock: 140 mm * 152 mm
Rated Power: 300 HP to 500 HP
Emission Standard: N/A
KTA50 | 1227 – 1657 KW
Engine Type: 16 Cylinder
Displacement: 50.3 L
Bore x Strock: 159 mm * 159 mm
Rated Power: 1645 HP to 2220 HP
Emission Standard: N/A
QSK50 | 1044-1864 kW
Engine Type: 16 Cylinder
Displacement: 50 L
Bore x Strock: 159 mm * 159 mm
Rated Power: 1044 – 1864 kW @ 1800 – 1900 RPM
Emission Standard: N/A
